Olympus Tough TG5 camera

RM 404.46

The definitive high-image-quality Tough camera. Relive your adventures with the TG-5.

Whether it be in the mountains, on the beach, or in the snow, the Tough series can withstand the most punishing environments. The TG-5 is the pinnacle of the Tough series, and its new image sensor and new TruePic VIII image processor deliver significant improvements to image quality. It is equipped with a Field Sensor System which records various field data so you can recreate the shooting experience on your smartphone. Take this camera with you to make outdoor activities, such as mountain climbing and diving, even more fun.

FEATURES

Further advanced image quality and Tough performance

The TG-5 is equipped with the latest image sensor and image processor, and a bright f/2.0 high-resolution lens for high image quality. Its Tough performance and anti-fog dual-pane protective glass make for worry-free use in the harshest environments.

High-resolution f/2.0 lens

The TG-5 features both Tough performance and high image quality, along with a high-resolution, 4x optical zoom lens. The bright f/2.0 lens makes it possible to use a fast shutter speed to reduce subject blur even when capturing moving subjects in dark locations.

Conventional camera
f/ value: 3.9, shutter speed: 1/30 sec. (The dark lens prevents use of a faster shutter speed)
Camera with a bright f/2.0 lens
f/ value: 2.0, shutter speed: 1/125 sec. (The bright lens allows use of a faster shutter speed)

Folded optics zoom lens

This model achieves the brightest aperture value, f/2.0, for a folded optics type lens. Lenses developed with advanced optical technology are lavishly used, including a DSA (Dual Super Aspherical) lens for high image quality.

4.5-18.0mm (35mm equivalent: 25 - 100mm), f/2.0 - f/4.9, 4x zoom

DSA lens: Dual Super Aspherical lens
HR/HD lens: High Refractive Index & Dispersion lens
Aspherical lenses

Bright 4x zoom lens

The TG-5 is equipped with a 4x optical zoom lens. The lens provides a broad range of photography, from a wide-angle bird's-eye view of scenic landscapes to zoomed-in telephoto close-ups of distant subjects.

Wide angle (35mm equivalent: 25mm)
Telephoto (35mm equivalent: 100mm)

New image sensor and image processor

To maximise the capabilities of the high-resolution f/2.0 lens, a new high-speed back-illuminated CMOS image sensor and the TruePic VIII image processor used on the OM-D E-M1 Mark II are included on this model. Noise level has been reduced by 1 step for shooting in the standard ISO sensitivity range and also for shooting in darker areas. These improvements result in even higher image quality.

Conventional camera
TG-5

Image processing that delivers high resolution

The image processing algorithms have been retooled to deliver even higher resolution on the TG-5. They have been modified to provide high resolution for sections with a low difference in contrast particularly when using a low ISO sensitivity setting.

Improved high-sensitivity performance

Maximum ISO sensitivity is now ISO 12800.

RAW photography

The TG-5 allows shooting in RAW format. RAW images can be edited and processed on a computer using the digital workflow software Olympus Viewer 3. Adjust the contrast and sharpness after shooting to achieve the exact results you have in mind.

Tough performance^[1]

In addition to being dustproof, waterproof up to 15m deep, shockproof up to a 2.1M drop, crushproof up to 100 kgf, and freezeproof down to -10℃, the TG-5 has anti-fog dual pane protective glass. Such Tough performance provides peace of mind when shooting in punishing environments such as the mountains, ocean, and snow.

Constructed to perform anywhere

This model features hermetic sealing, a floating lens construction, double-lock covers, and dual pane protective glass. It is such construction that makes the TG-5 waterproof, dustproof, shockproof, and anti-fog.

Hermetic sealing
Dual pane protective glass

15 m waterproof^[1]

The camera is waterproof up to 15m below the water. Not only does this make it possible to shoot in heavy rain, but it also lets you shoot while snorkeling.

Waterproof performance is JIS/IEC protection class 8 (IPX8) equivalent.

Dustproof^[1]

This design features an airtight construction that shuts out sand and dust. Because you can rinse off the camera body with tap water, even if it gets dirty you can simply wash it off.

Dust proof performance is JIS/IEC protection class 6 (IPX6) equivalent.

2.1 m shockproof^[1]

Even with a large, bright f/2.0 lens, this model can still clear drop tests of up to 2.1m. Olympus know-how has been utilised in every facet, including the lens shape, lens positioning, and the lens drive method, resulting in a high level of shock-absorbing performance.

The TG-5 is built with a shockproof construction resistant to 2.1 m (MIL-STD810F standard compliant).

100 kgf crushproof^[1]

To protect all inner parts including the lens unit and circuit boards, an interior protective structure which can withstand a weight of 100kgf has been employed. With such crushproof construction, you won't have to worry about accidentally sitting on your camera when carrying it in your back pocket.

-10℃ freezeproof^[1]

Operation at low temperatures is guaranteed down to -10℃. With this feature, you can feel confident taking it along on ski and snowboard trips and other winter sport outings.

Anti-fog^[1]

The TG-5 introduces a new Tough feature, anti-fog. The dual-pane protective glass provides an airtight seal that protects the lens and minimises condensation on the lens that tends to occur during sudden changes in temperature.

1. All tests were performed under Olympus in-house test conditions, however Olympus does not guarantee against damage or malfunction in all situations.
Pictures are for illustrative purposes only.

Specifications

Product Type

Memory	SD, SDHC^[1], SDXC^[1], Eye-Fi Card compatible^[2] 1 UHS-I compatible. 2 Not compatible with Endless mode.

Image Sensor

Product type	1/2.33 inch
Number of pixels	Number of effective pixels: 12 million pixels Total number of pixels: Approx. 12.7 million pixels
Aspect ratio	Aspect ratio: 1.33 (4:3)

Lens

Structure	9 lens elements in 7 groups
Focal length (equiv. 35mm)	4.5mm -18.0mm (25mm - 100mm)
Maximum aperture	f/2.0 (wide-end) to f/4.9 (tele-end)
Optical zoom	4x
Shooting range (from lens tip)	Throughout entire zoom range: 0.01m - infinite (Super Macro: 0.01m - 0.30m)

Still Photo Recording

Recording format	DCF2.0, Exif2.3
File format	RAW (12-bit lossless compression), JPEG, RAW + JPEG
Recording image size	[RAW] 4000 x 3000 [JPEG] 4000 x 3000 - 640 x 480

Image Stabilisation System

Type	Still image: CMOS shift
Mode	ON / OFF
Stabilisation performance	2.5 EV^[*] (Focal length set to 18 mm. 35 mm Equivalent Focal Length: 100 mm) Based on CIPA measurement conditions.

Live View

Live View	Approx. 100% field of view, Exposure compensation preview, WB adjustment preview, Gradation preview, Face detection preview (up to 8 faces), Grid line, Display modes: Standard, Histogram, Highlight & Shadow, Level Gauge, Off

Monitor

Monitor type	3.0-inch colour LCD^[*] Approx. 460K dots (Aspect ratio: 3 : 2)
Brightness control	±7 levels

Focusing

AF system	CMOS Contrast Detection (with AF Illuminator)
Focusing point / Focusing point selection mode	25 point / All target, single target
Focus mode	Single AF (S-AF) / AF tracking / Manual Focus (MF)
Face detection AF	With
Manual focus assist	Focus ring rotation activates Live View image magnification and/or focus peaking when in S-AF+MF or MF mode
Peaking function	With Colour selection: white, black, red, yellow
AF illuminator	With

Exposure Control (Still)

Metering system (TTL Image sensor metering)	Digital ESP metering / spot metering
Metering range	EV 2-20 (f/2.0 / ISO 100)
Exposure mode / Shooting mode	Intelligent Auto (iAUTO), Programme Auto (P), Aperture Priority (A), Custom1, Custom2, Underwater, Microscope, Scene Mode (SCN)
Scene select AE	Portrait, e-Portrait, Landscape, Portrait +Landscape, Hand-held Starlight^[*], Nightscape, Portrait + Nightscape, Children , Sport , Candlelight, Sunset, Fireworks, Beach & Snow, Panorama, Live Composite, Backlight HDR 6 images automatically shot and combined into a single composite image
ISO sensitivity	AUTO ISO: 100 - 1600 with customisable upper limit from 100 to 12800 Manual ISO: 100 - 12800 (1/3 EV step)
Exposure compensation	±2 EV (1/3 EV step)
AE lock	Locks with a half-press of the shutter button

Shutter

Shutter Type/Shutter Speed	1/2 to 1/2000 sec. (Night Scene, A mode: up to 4 sec.)

Drive

Sequential shooting maximum speed	[Sequential shooting H]^[]: approx. 20 fps with selectable 10 / 20fps [Sequential shooting L]: approx. 5 fps [Pro Capture]^[]: approx. 10 fps Electronic Shutter
Maximum recordable frames prior to second release (for Pro Capture)	Approx. 5 frames
Sequential shooting maximum recordable frames^[*]	[Sequential shooting H] RAW: Max. 14 frames, JPEG (LN): Until card is full [Sequential shooting L] RAW: Max. 49 frames, JPEG (LN): Until card is full
Self-timer	Operation time: 12 sec., 2 sec., custom (Wait time: 1-30 sec., Number of shots: 1-10, Shot interval: 0.5 / 1 / 2 / 3 sec.)

Flash

Flash intensity control method	TTL Auto, Manual
Built-in flash	With
Flash mode	Auto, Red Eye Reduction, Slow sync.(1st curtain), Red-eye Slow sync.(1st curtain), Fill-in, Manual(1/1(FULL)-1/64), Flash Off
Synchronisation speed	Compatible with all shutter speeds
Flash intensity control	Up to ±2 EV in 1/3 EV steps

Wireless Flash Control

Compatible external flash	FL-50R, FL-36R, FL-300R, FL-600R, FL-900R
Control method	Triggered and controlled by Olympus Wireless RC Flash system Commander Flash: Built-in flash
External Flash intensity type	TTL Auto, Auto, Manual, FP-TTL-AUTO, FP-MANUAL
Channel	1 channel
Group No.	1 group

White Balance

White balance mode	Auto WB, 7 Preset WBs, 4 Capture WBs, Custom WB (Kelvin setting)
White balance compensation	±7 steps along A-B / G-M axis Except for Custom WB

Colour Mode

Colour matrix	sRGB, Adobe RGB

Picture Mode

Mode	i-Enhance, Vivid, Natural, Muted, Portrait, Monotone, Custom, e Portrait, Art Filters
Gradation	Auto, Normal, High Key, Low Key [except when using i-Enhance, Underwater, Art Filters, Colour Creator]

Art Filter

Art Filter (Variation / Art Effect)	Pop Art (I, II / a, b, c. d, e, f) Soft Focus ( - / c, e) Pale & Light Colour (I, II / a, b, c, d, f) Light Tone ( - / d, f) Grainy Film (I, II / b, c, d, g, h) Pin Hole (I, II, III / d) Diorama ( I,II / d) Cross Process (I, II / b, c, d, f) Gentle Sepia ( - / a, b, c, d, f) Dramatic Tone (I / b, c, d, e, f) (II / b, c, d, e, f, g, h) Key Line (I, II / a, b, c, d, e) Watercolour (I, II / a, b, c, d) Vintage (I, II, III / a, b, c, d, e, f, i) Partial Colour (I, II, III / a, b, c, d, e, f)
Detail of Art Effect	a. Soft Focus Effect b. Pin-Hole Effect c. White Edge Effect d. Frame Effect e. Star Light Effect f. Blur Effect (Top & bottom, Left & Right) g. B&W Effect (None, Yellow, Orange, Red, Green) h. Pict. Tone (None, Sepia, Blue, Purple, Green) i. Shade Effect (Top & bottom, Left & Right)
Colour Ring (for partial colour)	18 colour selectable

Bracketing

Focus bracketing	Number of images 10 / 20 / 30 Focus step: Wide / Standard / Narrow
Focus stacking	With^[*] Angle of view becomes slightly smaller

HDR Function

HDR(Auto composite)	HDR^[*] SCN position

Live Composite

Update interval time / composite method	0.5sec - 4.0 sec / Lighten Mode (Bright area prioritisation)

Interval Mode

Interval Mode	Interval Time 1sec. - 24 Hours, Max 299 frames. Available to make Time Lapse movies automatically

Multi Aspect

Aspect Ratio	4:3, 3:2, 16:9, 1:1, 3:4

One Push Tele-converter

Magnification	x2 / x4 ^[*] Microscope Control mode only

Level Gauge

Detection	2-axis

Video Recording

Recording format	MOV(MPEG-4AVC/H.264)
Mode / frame rate / compression method	[MOV] 3840x2160(4k) / 30p, 25p (Bit rate: Approx. 102Mbps) 1920x1080(FHD) / 30p, 25p / IPB (SF, F, N) 1920x1080(FHD) / 60p, 50p / IPB (SF, F, N) 1280x720(HD) / 30p,25p / IPB(SF, F, N) 60p: 59.94fps, 50p: 50.00fps, 30p: 29.97fps, 25p: 25.00fps FHD IPB (Superfine / 52Mbps, Fine / 30Mbps, Normal / 18Mbps) HD IPB (Superfine / 52Mbps, Fine / 30Mbps, Normal / 18Mbps) Frame rates may drop when particular Art Filters and Movie Effects are used. SD cards of Speed Class 10 or greater are recommended for shooting movies. UHS-I Speed Class 3 SD cards must be used for 4K video and high speed movie.
Maximum recording time	[MOV] Approx. 29min
Art Filter Movie	With (Frame rates may drop when certain Art Filters are used)
Time Lapse Movie	[MOV] 3840×2160 (4K) / 5fps 1920×1080 (FHD) / 5fps, 10fps, 15fps 1280×720 (HD) / 5fps, 10fps, 15fps, 30fps
High Speed Movie	1920x1080 (FHD) / 120fps 1280x720 (HD) / 240fps 640x360 (SD) / 480fps
Image Stabilisation for Video	Digital stabilisation (angle of view becomes slightly smaller)
Grid Line	2 types of grid lines
Live View Output via HDMI	Monitor Mode (outputs video and info display to a connected monitor)^[*] Info display is not shown on the camera while recording.
Exposure Control	Programme AE

Recording (Sound)

Recording format	Wave format (Stereo linear PCM/16-bit, Sampling frequency 48kHz)
Microphone / Speaker	Built-in stereo microphone / built-in mono speaker
Microphone function	Wind noise reduction, recording volume, microphone volume limiter Audio dubbing possible for still pictures (up to 30 sec.) May affect audio quality.

Wi-Fi Function

GPS info. Function	Via smartphone GPS data
Wireless Control^[*] Using the OI.Share app	Live View, Rec View, Wireless Touch AF shutter, Self Timer (w/countdown guidance, consecutive shooting, short video recording), power off, wireless release, video recording (video quality is restricted) iAuto / P / A / and Live Composite can be selected.^[] Aperture, exposure, ISO sensitivity, white balance can be adjusted.^[] When in private connection
Image Share	File Type: JPEG, MOV Connect to up to 4 devices simultaneously. Marking function for image share.
Easy Connection	QR code setting

Playback

Playback mode	Single-frame, information display, index display (4 / 9 / 25 / 100 frames), calendar, enlargement (2x - 14x), movie (with sound, FF / REW / Pause), slideshow (with sound including BGM, picture rotation (auto)
Information display	Histogram (independent luminance / RGB available), Highlight / Shadow point warning, AF frame, Photographic information, OFF

Image Editing

Movie Editing function	Trimming (beginning / end) / in-movie image extraction (4K only)
Editing function	RAW data edit, Gradation auto, Monochrome, Sepia, Red-eye fix, Saturation, Resize (1280x960, 640x480, 320x240), Trimming, Aspect, e-Portrait, Image Overlay, Post recording
RAW data edit	RAW data edit based on settings of the camera (including e-Portrait, Colour Creator, Art Filter, ART-BKT). Preview capability.

Print

Print function	Print reservation (DPOF), Direct print (PictBridge compatible)

Languages	34 languages selectable: English, French, German, Spanish, Italian, Japanese, Korean, Traditional Chinese, Simplified Chinese, Russian, Czech, Dutch, Danish, Polish, Portuguese, Swedish, Norwegian, Finnish, Croatian, Slovenian, Hungarian, Greek, Slovakian, Turkish, Latvian, Estonian, Lithuanian, Ukrainian, Serbian, Bulgarian, Rumanian, Indonesian, Malay, Thai

Tough Capabilities

Waterproof	15m Equivalent to JIS/IEC protection class 8 (IPX8)
Dustproof	Equivalent to JIS/IEC protection class 6 (IP6X)
Freezeproof	Down to -10℃
Crushproof	Up to 100 kgf
Shockproof	Up to 2.1 m

Field Sensor System

Sensor	GPS (GLONASS,QZSS), compass, manometer, temperature sensor, Acceleration sensor

Custom

Mode dial my set	Modes C1 and C2 can be accessed by mode dial
Copyright Settings	With

Input / Output

Remote controller connector	USB microB
HDMI connector	Micro HDMI (type D)
Wireless LAN	Built-in (IEEE 802.11 b / g / n)
PC interface	USB2.0 Hi-Speed
DC connector	USB micro B

Power Requirements

Battery	LI-92B Li-ion battery
AC Adapter	F-5AC
Number of recordable images	Approx. 340 shots (using Toshiba SDHC UHS-I Card Exceria with IS ON, based on CIPA test standards)
Battery life for movie recording	Approx. 50 minutes^[*] (under standard JEITA testing) Approx. 110 minutes (when zoom and other operational functions are not used) When repeatedly recording at the maximum time of 29 minutes

Dimensions / Weight

Dimensions	W: 113 mm H: 66 mm D: 31.9mm (based on CIPA standards: excludes protrusions)
Weight	Approx. 250 g (with a battery and memory card, based on CIPA standards)

Operating Environment

Temperature	-10 - +40℃ (when in operation) / -20 - +60℃ (when stored)
Humidity	30 - 90% (when in operation) / 10 - 90% (when stored)

Box contents

Box contents	Body, USB cable, Hand Strap, instruction manual, warranty card, LI-92B Li-ion battery, F-5AC USB-AC adapter
